P/N: 818017738

Mini RF I Plug to SMA Female, RG 1.2 Cable Brown. Frequency Range: DC~6GHz ; Frequency Range: -40℃～+85℃ ; Insulation Resistance: 100MΩ ; Dielectric Withstanding Voltage: 300V/AC ; Durability: 1000 Cycles ; Voltage Standing Wave Ratio: 1.60Max ; Insertion Loss: 3.0dB Max ; Rated Voltage: 60V AC ( R.M.S ) ; Inner Conductor Impedance: 100mΩ ; External Conductor Impedance: 100mΩ

P/N: 818022151

Mini RF I Plug to SMA Female, RG 1.2 Cable Brown. Frequency Range: DC~6GHz ; Frequency Range: -40℃～+85℃ ; Insulation Resistance: 100MΩ; Dielectric Withstanding Voltage: 300V/AC; Durability: 1000 Cycles ; Voltage Standing Wave Ratio: 1.60Max ; Insertion Loss: 3.0dB Max ; Rated Voltage: 60V AC ( R.M.S ) ; Inner Conductor Impedance: 100mΩ ； External Conductor Impedance: 100mΩ

P/N: 818017739

Mini RF II Plug to SMA Female, RG 1.2 Cable Brown. Frequency Range: DC~6GHz ；Frequency Range: -40℃～+85℃ ；Insulation Resistance: 100MΩ ；Dielectric Withstanding Voltage: 300V/AC ；Durability: 1000 Cycles ；Voltage Standing Wave Ratio: 1.60Max ；Insertion Loss: 3.0dB Max ；Rated Voltage: 60V AC ( R.M.S ) ；Inner Conductor Impedance: 100mΩ ；External Conductor Impedance: 100mΩ

P/N: 818017505

Mini RF III Plug to SMA Female, 1.20 Cable Black. Frequency Range: DC~6GHz ; Frequency Range: -40℃～+85℃ ; Insulation Resistance: 100MΩ ; Dielectric Withstanding Voltage: 300V/AC ; Durability: 1000 Cycles ; Voltage Standing Wave Ratio: 1.60Max ; Insertion Loss: 3.0dB Max ; Rated Voltage: 60V AC ( R.M.S ) ; Inner Conductor Impedance: 100mΩ ; External Conductor Impedance: 100mΩ

P/N: 818021014

Mini RF III Plug to SMA Female, 1.20 Cable Black. Frequency Range: DC~6GHz ; Frequency Range: -40℃～+85℃ ; Insulation Resistance: 100MΩ ; Dielectric Withstanding Voltage: 300V/AC ; Durability: 1000 Cycles ; Voltage Standing Wave Ratio: 1.60Max ; Insertion Loss: 3.0dB Max ; Rated Voltage: 60V AC ( R.M.S ) ; Inner Conductor Impedance: 100mΩ ; External Conductor Impedance: 100mΩ

P/N: 818017663

Mini RF IV Plug to SMA Felmale, 1.13 Cable Black. Frequency Range: DC~6GHz ; Frequency Range: -40℃～+85℃ ; Insulation Resistance: 100MΩ ; Dielectric Withstanding Voltage: 300V/AC ; Durability: 1000 Cycles ; Voltage Standing Wave Ratio: 1.60Max ; Insertion Loss: 3.0dB Max ; Rated Voltage: 60V AC ( R.M.S ) ; Inner Conductor Impedance: 100mΩ ; External Conductor Impedance: 100mΩ

P/N: 818016475

Mini RF V Plug to SMA Male, 1.13 Cable Brow. Frequency Range: DC~6GHz ; Frequency Range: -40℃～+85℃ ; Insulation Resistance: 100MΩ ; Dielectric Withstanding Voltage: 300V/AC ; Durability: 1000 Cycles ; Voltage Standing Wave Ratio: 1.60Max ; Insertion Loss: 3.0dB Max ; Rated Voltage: 60V AC ( R.M.S ) ; Inner Conductor Impedance: 100mΩ ; External Conductor Impedance: 100mΩ

P/N: 818021698

SMPM Cable 5.8*5.8*3.1φ1.37, L400, SMA-F. Frequency Range: DC~8GHz ; Frequency Range: -40℃～+85℃ ; Insulation Resistance: 100MΩ ; Dielectric Withstanding Voltage: 500V/AC ; Durability: 100 Cycles ; Voltage Standing Wave Ratio: 1.50Max ; Insertion Loss: 2.9dB Max ; Rated Voltage: 60V AC ( R.M.S ) ; Inner Conductor Impedance: 100mΩ ; External Conductor Impedance: 100mΩ
